OEM Service Industrial Drive In Radio Shuttle Rack Mattress Warehouse Racking
Drive In Racking is also known as Through racking, which consists of frame, top beam, Top and back bracing,support bar and supporl rail . High-intensive structure, the distance between upright and upright connects together which rely on the top beam. The depth of racking is mainly composed of the bar and support rail, which connects the frame together. Usually it uses reach forklift or counterbalanced forklift to operate. when it strores or accesses pallets, forklift is operating which needs through the main channel into and out of library going into shelf storage channel.
Drive-In or Double Access Systems consist of continuous lanes of racking with only a single load and retrieval aisle. Loading and unloading is undertaken by means of counter balance or reach trucks that drive down each lane into the racks.
Drive-In rack operates on the system of First-In Last-Out (FILO), therefore it only suits products that is stored in sufficient volume to require multiples lanes to ensure stock rotation.
This system is base on the storage by accumulation principle, which enables the highest use of available space in terms of both area and height.
Drive-in racking is designed for the storage of homogenous products. It accommodates a large number of pallets for each SKU.
Advantages
| 1 | - Maximum profitability of the available space (up to 85%).
|
| 2 | - Removal of aisles between the ranking.
|
| 3 | - Rigorous control of entries and exits.
|
| 4 | - It allows as many SKU as loading lanes.
|
Two management systems are available: the drive-in system, with only one access aisle, and the drive-through system, with access to the load from both sides of the rack.
The system is frequently used in cold stores (refrigeration and freezing) which require maximum use of space for the storage of products in a controlled temperature.
| Product name | Drive In Rack/Warehouse |
| Features | Material: Cold-rolled Steel Surface treatment: Electrastic Spray Size: Customized Color: Optional OEM/ ODM: Accepted Feature: Corrosion Protection |
| Specification | This rack can be safe to keep goods. The space and load capacity for each tier are more large than common commercial shelves.
Different thickness,size,layers,and colors are available for you to choose. |
| Others | Minimum order quantity: 10 sets
Supply ability:5000 pieces per month
Payment terms: 30% deposit upon signing the contract,the balance will be cleared by T/T before delivery.
Delivery Terms: Upon factory
Delivery Time: 10-15 workday upon receipt of the deposit |
Product specification of the drive-in rack
| Racking Specs(LXW :mm) | Pallet Specs(LXW:mm) |
| 1650X1450 | 1400X1400 |
| 1650X1250 | 1400X1200 |
| 1650X1050 | 1400X1000 |
| 1550X1350 | 1300X1300 |
| 1550X1250 | 1300X1200 |
| 1550X1150 | 1300X1100 |
| 1550X1050 | 1300X1000 |
| 1450X1250 | 1200X1200 |
| 1450X1050 | 1200X1000 |
Features of pallet racks:
1. Pallets can be located, accessed and moved individually.
2. Rapid handling of almost all types of palletized goods.
3. Infinitely adjustable and offering a wide range of options and components to accommodate specialized needs.
4. Maximizes space use in any warehouse configuration while retaining optimum product accessibility.
5. Strength and rigidity prevents compression damage to goods.
6. Bottom level of pallets can be stored on the floor, lowering structure costs.
